P5-NS2 is a wireless device for remote control of point-to-point lighting. P5-NS2 belongs to the family of P5 light point controllers, capable of communicating with each other to form a mesh-type WSN (Wireless Sensor Network), a network topology capable of reliably covering large areas.Installed on standard plinth NEMA-7, guarantees real-time management and diagnostics of the light point and supports DALI, DALI 2 and 0-10V standards. P5-NS2 integrates a clock astronomical with backup supercap, a 3-axis accelerometer, a temperature sensor, a relay, a luxmeter and a power meter high precision. Version is also optionally available with GPS and with M2M 2G, 3G or NB-IoT modem.

P5-NS2 is a wireless device for remote control of point-to-point lighting.

Management of the light point from the centre check
Astronomic watch

OTA Firmware Update (Over the air)

Supports DALI, DALI-2 and 0-10V drivers

Compatible with CAM profiles

Product Specifications

Wireless communication and lighting control Point-to-point device based on NEMA-7 socket

Input voltage: 120 – 277 Vac

Supported protocols: DALI, DALI-2 e 0-10V

DALI management: Up to 8 DALI addresses managed

Overvoltage protection: 6 kV common mode, 10 kV differential mode
